Specification
| General Description |
2-way centre speaker |
| Enclosure Type |
bass reflex |
| Transducer Complement |
2-way |
| Bass Driver |
5"(130mm)
Black woven Kevlar cone x 2 |
| Full Range Driver |
1"(25mm) soft dome |
| Sensitivity (2.83v @ 1m) |
89dB |
| Peak Power Handling |
25-120W |
| Peak SPL |
95dB |
| Nominal Impedance |
4Ω (compatible 8Ω ) |
| Minimum Impedance |
3.8Ω |
| Frequency Response (+/-3dB) |
65Hz ~ 20kHz |
| Bass Extension (-6dB) |
55Hz |
| Crossover Frequency |
2.5kHz |
| Dimensions ( H x W x D ) |
(180+10) x 510 x (200+32)mm |
| Net Weight |
8.0kg/pcs |
|
